Product Features
◎ It can periodically and actively report meter readings.
◎ It has remote valve closing and opening functions.
◎ This water meter supports prepaid and pre-purchased volume.
◎ It has a built-in early warning system. When there is low battery, abnormal metering, or when the pre-purchased volume and prepaid amount reach the threshold, it sends an alarm prompt. Different emergency water consumption can be set according to different users.
◎ It has a built-in memory with large-capacity storage function, which can store monthly frozen data for up to 24 months.
Flow Parameters
| Nominal DiameterDn(Mm) | Overload FlowRate Q4(M³/h) | Common FlowRate Q₃ (M³/h) | Transitional FlowRate Q₂ (M³/h) | Min.flow-rateQ₁ (M³/h) | Range RatioR(Q₃/q₁) | Accuracy Class | Temperature Class |
| DN15 | 1.25×Q₃ | 2.5 | 1.6×Q₁ | Q³/R | 100 | Class 2 | T30 |
| DN20 | 1.25×Q₃ | 4 | 1.6×Q₁ | Q³/R | 100 | Class 2 | T30 |
| DN25 | 1.25×Q₃ | 6.3 | 1.6×Q₁ | Q³/R | 100 | Class 2 | T30 |
Main Technical Parameters
| Electromechanical conversion mode | photoelectric direct reading |
| Electromechanical conversion accuracy | ±1m³ |
| Communication methods | LoRa/NB-loT |
